Vacuum Oven

ADP200C/210C/300C/310C

Description

Standard small size benchtop vacuum drying ovens with enhanced safety features

Performance and functions

  • Easy input of parameters and settings
  • Digital PID controller supports fixed temperature, quick auto-stop, auto stop, auto start and program operations
  • Self-diagnostic and overheating prevention functions
  • Silicon rubber door seal prevents air from leaking
  • Independent over heating prevention device for each circuit
  • Customizable with N₂ gas inlet and communication ports
  • Calibration off-set function
  • Easy maintenance

Safety features

  • Sensor trouble detection, SSR, short circuit detection, heater disconnecting  detection,  memory  error,  overheating  and measurement temperature error
ModelADP200C
ADP210C
ADP300C
ADP310C
SystemVacuum drying by decompressed chamber direct heating
Operating temp. range40~240°C
Operating pressure range101~0.1kPa (760~1 Torr)
Temp. control accuracy±1.5°C (at 240°C)
Max. temp. reaching time~70min.~100min.
Interior materialStainless steel
Temp. control methodPlD control by microprocessor
SensorK-thermocouple
Temp. setting methodDigital setting by ▲/▼ keys
Temp. display methodMeasurement temp.: Digital display by green LED / Setting temp.: Digital display by red LED
Timer1 min. to 99 Hrs. 59 min. and 100 Hrs. to 999 Hrs. and 50 min. / Digital display
HeaterMica heater / 0.68kWMica heater / 1.05kW
Heat insulating materialRock wool
Observation windowTempered glass (12 mm thickness) and polycarbonate resin plate
Vacuum gaugeBourdon tube type, 0~0.1 MPa (Gauge pressure)
Safety deviceSelf diagnostic functions (Heater, Sensor, SSR short circuit, automatic overheat prevention function), over current electric leakage breaker, overheating prevention device
Internal dimensions WxDxH200 x 250 x 200mm300 x 300 x 300mm
External dimensions WxDxH400 x 412 x 603mm500 x 465 x 705mm
Internal capacity10L27L
Shelf loading~15kg / pcs
Shelf rest step number2 steps3 steps
Shelf rest pitch65mm75mm
Vacuum portO.D.18mm
Power sourceAC115V 6A (with plug)
AC220V 3.5A (no plug, round terminal)
AC115V 9.5A (with plug)
AC220V 5A (no plug, round terminal)
Weight~30kg~55kg
AccessoriesShelf plate (Aluminum perforated metal) 2 pcs.Shelf plate (Aluminum perforated metal) 3 pcs.
